1. Why choose water treatment machine ?
The machining process of glass inevitably generates glass finings. These fine particles not only contaminate the process water, thereby adversely influencing the quality of the glass processing, but also lead to fine scratches on the glass surface when the glass grinding wastewater is recycled. Moreover, they have the potential to cause the water outlet of the glass processing machine to become clogged. This obstruction can result in the machine's inability to discharge water properly and make the equipment prone to rusting. Additionally, the grinding wheel is subject to excessive wear, the glass might undergo burning and even explosion, and the service life of the machine is significantly shortened as well. Therefore, it is of utmost necessity and significance to implement effective treatment measures for the glass edging wastewater.
The Minxin water treatment machine specifically designed for the glass manufacturing sector provides crucial assistance in supporting comprehensive water treatment solutions for the glass industry. It brings about remarkable benefits by not only significantly reducing the time and effort expended on cleaning the machine's wastewater treatment system but also by extending the service life of the glass processing machine through the provision of clean process water. This, in turn, leads to a substantial improvement in the quality of glass processing and a notable enhancement in the production efficiency.
2. Wastewater treatment process
The treatment process of this system is to collect wastewater discharged from multiple glass edging machine or beveling machine, drill machine, CNC etc into a wastewater collection pool, an aeration system is installed at the bottom of the wastewater collection pool to prevent glass powder from settling at the bottom of the pool and ensuring glass powder’s concentration distribute more evenly in the water. Compared to traditional sedimentation devices, this aeration system can let all glass powder pump to the integrated reaction tank for wastewater treatment. The wastewater is pumped to the integrated reaction tank, at the same time, the flocculant-mixed wastewater is pumped to the integrated reaction tank through the dosing system for wastewater treatment. The integrated reaction tank integrates water pumping, dosing, reaction, and drainage. The treated clean water is discharged to the clean water collection pool for glass edge grinding, which can greatly reduce the blockage and damage of the water nozzle of the glass edge grinding machine, extend the service life of the machine and improve the edge grinding efficiency. The solid waste treated by the efficient integrated reaction tank is discharged into the sludge collection pool. and then pumped to the filter press to press it into a solid glass cake. the filtered clean water can be discharged to the wastewater collection pool or clean water collection pool.
3. Glass manufacturing water treatment configuration
4. Features
(1). The equipment operates using a fully automated siemens control system, without the need for dedicated personnel to be on duty.
(2). The water treatment capacity is large, and the operating cost is low, which is one-third of the dosage of conventional water treatment equipment. The equipment is stable and has low failure rate.
(3). Fully automatic acid-base regulation, strict control of water quality.
(4). Fully automatic water level balance control, high sensitivity, no mis-operation, automatically adjust the water treatment rhythm based on the production water consumption.
(5). The equipment is directly connected to the filter press, without the need for manual control of the filter press. Fully automatic unloading and the residue is cake shaped solid waste, easy to handle.
(6). Fully automatic aeration system, the glass powder will not easy to settle on the bottom of the pool, and there is no need to clean the wastewater pool frequently.
(7). The fully automatic self-cleaning system prevents slag accumulation in the tank.
(8). The equipment can be equipped with pure water equipment, which can clean low-e glass, double silver glass, and ensure product quality.
(9). Intelligent cloud monitoring system, online mobile app monitoring device status, remote parameter modification, monitoring the quality of water, report output, etc.
(10). Clear water can be supplied to the workshop with constant pressure water supply, fully computer controlled, pressure sensor controlled frequency converter, constant pressure regulation, ensuring stable water supply in the workshop and playing a role in energy conservation and consumption reduction.
5. Treatment water quality effect
6. More than 600 installation cases in total
